HP NC365T 4-port Ethernet Server Adapter - Manual (Page 10)

Specifications 10
Specifications
HP NC365T specifications
Specification Value
Network Controller
Chipsets Intel 82580 MAC
Bus Type x4 PCI-Express v2.0
Bus Width Four lane
On-board Memory 56 KB
Data Transfer Method Bus Master DMA
Boot ROM Support Yes
Management Capabilities PXE 2.2, ACPI 1.1a
Power Requirement 5.0 Watts @ 3.3v
Data Transmission Rate 10 Full/10 Half, 100 Full/100 Half, 1000 Full
Standards Supported IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.3ad,
IEEE802.1p, IEEE802.1Q, IEEE802.3z, IEEE158, IEEE802.1as
Dimensions 10.92 cm x 6.86 cm [4.3 in x 2.7 in (L x W)] (without bracket)
Connector and Distances 10BASE-T: Category 3, 4, or 5 UTP 100 M (328 ft)
100BASE-TX: CAT5 UTP 100 M (328 ft)
1000BASE-TX: CAT5 UTP 100 M (328 ft)
Interrupts Supported Automatically configured
Temperature Range Operating: 0°C to 55°C (32°F to 131°F)
Storage: -65°C to 85°C (-85°F to 185°F)
Relative Humidity (non-
condensing) Operating: 10% to 90%
Storage: 5% to 95%
Safety Compliance UL Mark (US and Canada)
CE Mark
EN 60590
RoHS (European Union)
UTP cable specifications
The NC365T adapter can use existing UTP CAT5 (or better) cable to deliver Gigabit Ethernet over
copper, according to the IEEE 802.3ab specifications. For new installations, CAT5e (enhanced CAT5)
cable is recommended.
