Chapter 1 Before You Begin 13
Hardware Components and LEDs
This section describes the main hardware components of your storage system
enclosures.
Controller Enclosure Components and LEDs
The controller enclosure can be connected to Fibre Channel host bus adapters
(HBAs) or switches. Table 1-1 describes the controller enclosure components.
Table 1-1 Controller Enclosure Components
Description Quantity
FC controller (I/O) module 1 or 2 1
1 Air-management system drive blanks or I/O blanks must fill empty slots to maintain optimum airflow through the chassis.
SAS or SATA drive module 2–12 per enclosure
AC power-and-cooling module 2 per enclosure
2- or 4-Gbps FC host port with SFP 2 per controller module
3-Gbps, 4-lane SAS expansion port 1 per controller module
Ethernet port (RJ-45) 1 per controller module
CLI port (RS-232 micro-DB9) 1 per controller module
Service port (RS-232 3.5-mm jack) 1 per controller module
