Hardware information screens 210
The following table describes the rows within the Uplink Port information table in the Bay Summary
screen.
Column Description
Port The uplink port number
WWN World Wide Name assigned to the port or Server Factory Default if not
assigning WWNs
SAN Fabric Name of the SAN Fabric connected to the uplink port
Port Speed Speed setting of the uplink port
Connector Status Status of the uplink port
Connected To MAC address of the device that this port is connected to on the other end.
The device must support LLDP to display this information.
The following table describes the rows within the Server Port Information table in the Bay Summary
Screen. Click Less < to display only the Port, Server Blade, SAN Fabric, Connected To, and Profile
columns. Click More > to display all columns.
Column Description
Port Port number
Server Blade Bay location of the server blade
SAN Fabric Name of the SAN FAbric connected to this port
Connected To MAC address of the device that this port is connect to on the other end. The
device must support LLDP to display this information.
Profile Server Profile(s) with connections to this port
HBA Port HBA port number
HBA Port Speed Speed setting of the HBA Port
HBA Port Status Status of the HBA port
HBA WWPN World Wide Port Name assigned to the port or Server Factory Default if not
assigning WWNs
Administrative module removal
The Remove from Domain feature enables users to remove an interconnect module from the Virtual
Connect domain without having to delete the entire domain, or having the bay permanently configured
for a specific interconnect module type.
To temporarily remove the module from the domain, do not click Remove from Domain. Simply re-install it
into the enclosure.
To permanently remove the module from the Virtual Connect domain be sure the following conditions are
met:
NOTE: The attachment of stacking link cables to a module does not prevent a Remove from
Domain action.
VC-Enet conditions:
• The user must have Domain privileges.
