Network management 123
Field name Description
VLAN ID Displays the VLAN ID number
Native Select whether native VLAN is enabled (checked) or disabled (unchecked)
Smart Link Select whether Smart Link is enabled (checked) or disabled (unchecked)
Private Network Select to designate (checked) or not to designate (unchecked) this network
as a private network
Advanced Displays icon that accesses advanced network settings
The following table describes the available actions in the Define New Shared Uplink Set screen. Clicking
another link in the pull-down menu or left navigation window causes current edits that have not been
applied to be lost.
Task Action
Add an external port Click the down arrow on Add Port. Select the enclosure, bay number, and
port number.
Set the Port Role to primary or
secondary Click the down arrow in the Port Role column and select Primary or
Secondary.
Change the uplink interface
port speed or disable the port
Click the drop-down box under Speed/Duplex, and then select a setting.
Delete a port Click the Delete icon in the Delete column of the port to be deleted.
Change connection mode Click the down arrow in the box next to Connection Mode, and then select
Auto or Failover. For information on Connection Modes, see "Defining a
shared uplink set (" Define New Shared Uplink Set screen " on page 121 )."
Add an Associated Network Click Add Network.
Enable native VLAN on the
network being defined
Select the box under Native. Only one network can be designated as the
native VLAN.
Enable or disable Smart Link on
the network being defined Select the box under Smart Link.
Designate or do not designate
this network as a private
network
Select the box under Private Network.
Set a custom value for
preferred link connection speed
or maximum link connection
speed
Click on the Advanced icon for the line item to be changed.
Edit associated network
properties
Click on the Edit icon for the line item to be changed.
Delete an associated network Click on the Delete icon for the line item to be deleted.
Defining a shared uplink set
To define a shared uplink set, use the following steps:
1. Enter the shared uplink set name. The uplink set name can be up to 64 characters in length (no
spaces).
