HP Slate 500 Tablet PC - Manual (Page 28)

Using a WLAN
A wireless connection connects the Slate to Wi-Fi networks, or WLANs. A WLAN is composed of
other computers and accessories that are linked by a wireless router or a wireless access point.
Connecting to an existing WLAN
To connect to the WLAN, follow these steps:
1. Be sure that the WLAN device is on.
2. Tap the Wireless icon in the notification area, at the far right of the taskbar.
3. Tap your WLAN from the list.
4. Tap Connect.
If the network is a security-enabled WLAN, you are prompted to enter a network security key,
which is a security code. Type the code, and then tap OK to complete the connection.
NOTE: If no WLANs are listed, you are out of range of a wireless router or access point.
NOTE: If you do not see the network you want to connect to, tap Open Network and Sharing
Center, and then tap Set up a new connection or network. A list of options is displayed. You
can choose to manually search for and connect to a network or to set up a new network
connection.
After the connection is made, place the pointer over the network icon in the notification area, at the far
right of the taskbar, to verify the name and status of the connection.
NOTE: The functional range (how far your wireless signals travel) depends on WLAN
implementation, router manufacturer, and interference from other electronic devices or structural
barriers such as walls and floors.
Setting up a new WLAN
Required equipment:
● A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from
an Internet service provider (ISP)
● A wireless router (purchased separately) (2)
NOTE: Some cable modems include a built-in router. Check with your ISP to see if you need a
separate router.
● Slate equipped with a wireless device (3)
The following illustration shows an example of a wireless network installation that is connected to the
Internet.
20 Chapter 3 Networking (select models only)
