Optional Features
142 HA-Fabric Manager User Guide
6. To insert a macro for values from the trigger’s content, perform the following:
a. Click in the Value column.
b. Right-click and choose an argument from the menu.
7. Click Add.
Specifying a Log Action
You can configure an additional master log entry that includes a custom
description.
Note: Before specifying an action, you should specify the rule’s triggers. See “ About
Triggers ” on page 128 for instructions.
1. Click the Event Management tab on the main window. The Event
Management tab displays, as shown in Figure 69 on page 133.
2. Click New. The Add Rule dialog box displays, as shown in Figure 70 on
page 134.
3. Choose Log from the Actions list at the bottom left side of the dialog box.
The Log information displays, as shown in Figure 76 .
Figure 76: Add Rule dialog box (Log)
4. Choose an option from the To parameter’s value.
5. Choose an option from the Level parameter’s value.
