Installation and configuration 16

If the drives are hot-plug capable, connect the internal connector of the controller to the SAS

connector on the hot-plug drive cage.

If the drives are not hot-plug capable, connect the internal connector of the controller to the
non-hot-plug drives.

Close or install the access panel, and secure it with thumbscrews, if any are present.

CAUTION:

Do not operate the server for long periods with the access panel open or removed.

Operating the server in this manner results in improper airflow and improper cooling that can

lead to thermal damage.

Power up the server.

Cable part numbers

For more information on the following cables, see the server QuickSpecs on the HP website
(

http://www.hp.com/go/productbulletin

Description

Option kit part number

Notes

HP Internal SAS 68-pin
SFF-8087 2x36-pin SFF-8087

Left Exit Cable

730603-B21

For the HP ProLiant DL360p Gen8 Server and
HP ProLiant DL360p Gen8 SE Server SFF

models.

HP Internal SAS 68-pin
SFF-8087 1x36-pin SFF-8087

Left Exit Cable

730612-B21

For the HP ProLiant DL360p Gen8 Server LFF

model

HP P430 Enablement Cable
Kit

740024-B21

For the HP ProLiant SL270s Gen8 Server

HP Mini-SAS P430/P830
Cable Kit

718409-B21

For the HP ProLiant SL210t Gen8 Server

HP ML350p Gen8 Smart

Array Cable Kit

725675-B21

For the HP ProLiant ML350p Gen8 Server

HP 6G SAS P430/830
Primary Cable Kit

729278-B21

For the HP ProLiant DL380p Server and the HP
ProLiant DL385p Gen8 Server 8SFF model

HP 6G SAS P430/830

Secondary Cable Kit

729276-B21

For the HP ProLiant DL380p Server and the HP

ProLiant DL385p Gen8 8+8SFF model

HP DL38Xp Gen8 12 Large
Form Factor (LFF) P430/830

Cable Kit

729272-B21

For the HP ProLiant DL380p Server and the HP
ProLiant DL385p Gen8 Server 12LFF model.

HP DL38Xp Gen8 25 Small
Form Factor (SFF) P430/830

Cable Kit

729274-B21

For the HP ProLiant DL380p Server,the HP

ProLiant DL385p Gen8 Server 25SFF model,
and the HP ProLiant DL560 Gen8 Server.

HP DL580 Gen8 SAS

Controller Cable Kit

748916-B21

For the HP ProLiant DL580 Gen8 Server
