Introducing the OmniBook
OmniBook Features
12 User’s Handbook
OmniBook Features
OmniBook—Front View
1. Keyboard status lights (left to right: caps lock,
keypad lock, num lock).
2. Built-in microphone.
3. Blue power button. Turns the OmniBook on and
off.
4. Pointing stick (pointing device).
5. Touch pad (pointing device).
6. Built-in speakers
7. Click buttons (two above and two below touch
pad).
8. Main battery release latch.
9. Mute button.
10. AC adapter jack.
11. Audio jacks (left to right): audio line-in, external
microphone, audio line-out.
12. PC Card eject buttons (upper and lower PC Card
slots).
13. PC Card and CardBus slots (upper and lower).
Accepts two Type-II cards or one Type-III card.
14. Main status lights (left to right): power state, hard
disk activity, charging status.
15. Latch to open and close the OmniBook.
