Zoning 166
6. Click Export Zone Set.
The file is saved to the specified folder.
7. Click OK.
Importing a zone set
To import a zone set XML file to a zone set library:
1. Display the zone library. (See ” Displaying the zone library ” on page 159.)
The Zoning dialog box is displayed ( Figure 98 on page 159).
2. Click Import.
The Import Zone Set dialog box is displayed (
Figure 104 ).
Figure 104 Import Zone Set dialog box
3. Locate the folder that contains the exported zone set.
4. Select the XML file and click Import.
NOTE: If the zone set name already exists in the zone set library, a warning message is displayed:
Unable to import zoneset. The zoneset name already exists
. Change the zone
set name and try again.
5. Click OK.
Zoning administration
This section describes zoning administrative tasks. Tasks that you can perform on zones and zone
sets include:
• Renaming a zone or zone set , page 167
• Replacing zone members , page 167
• Copying a zone set , page 168
• Deleting a zone , page 168
• Viewing zone and zone set properties , page 169
• Finding members in a zone , page 169
