1 Preparing your HP TouchSmart PC
for wall-mounting
This document provides instructions for computer wall-mounting preparation. The VESA adapter plate is
attached to bottom of the stand on the HP TouchSmart PC. This adapter assembly attaches to a wall-
mounting device (sold separately).
Should you decide to switch your computer back from a wall-mounted unit to desktop unit, instructions
are also included for reinstalling the stand on the computer. It is very important that you follow all the
steps to reinstall the computer stand.
What you need
● A Phillips screwdriver and a flathead screwdriver (magnetic-tipped recommended)
● A stable flat surface covered with a soft, clean cloth (such as a clean, large towel) to protect the
computer when you place it face down.
● Another person (it might require two people to lift and move the computer)
● Antistatic wrist strap and a conductive foam pad to stand on while working on the computer
(recommended)
● Wall-mounting device (sold separately) with the following specifications:
◦ VESA standard 100 mm x 100 mm (3.9 in x 3.9 in) hole pattern
or
◦ VESA standard 100 mm x 200 mm (3.9 in x 7.8 in) hole pattern
◦ Designed for flat-panel displays ranging in size from 508 mm to 582 mm (20 inches to 22.9
inches) diagonal, and weighing up to 22.7 kg (50 lb)
Safety information
This product has not been evaluated for connection to an “IT” power system (an AC distribution system
with no direct connection to the earth, according to IEC 60950).
WARNING! Please read “Additional Safety Information” in the Limited Warranty and Support
Guide before installing and connecting your system to the electrical power system.
WARNING! The computer is heavy. Take proper precautions when lifting or moving your computer.
WARNING! Always disconnect the HP TouchSmart PC from the power source before removing the
computer stand. Failure to do so before you perform any procedures can result in personal injury or
equipment damage.
WARNING! Avoid touching sharp edges inside the computer.
