1-5
The following numbers correspond to the numbers in the drawing on the
previous page.
1 Operation mode switch Used to choose the operating mode. Refer to
“Setting the Operation Mode” in this section.
2 SCSI ID switch Used to set the SCSI ID.
3 Power connector Connection for power cord.
4 On/Off switch Used to switch power on or off.
5 SCSI connectors Two connectors that allow SCSI devices to
be daisy-chained. If no other SCSI device ex-
ists on the chain after the optical drive, a ter-
minator must be connected to the unused
connector.
