Addonics Technologies AAT18ZIF25 User Manual
Page 2
www.addonics.com
Technical Support (M-F 8:30am - 6:00pm PST)
Phone: 408-453-6212
Email: www.addonics.com/support/query/
1.
Open the locking lever on the Toshiba 1.8” ZIF hard drive.
2.
Slide the flat ribbon cable of the converter into the ZIF connector on the
hard drive.
3.
Close the lever to secure the ribbon cable connection.
Connecting the Toshiba 1.8” ZIF hard drive to a 40-pin IDE connector
Master & Slave Pins
Pin 1
Lever
Toshiba 1.8” ZIF
(Zero Insertion Force)
Hard Drive
AA25IDE35 (optional)
