Power Indicator
Mode Product
On Mode
Sleep Mode
Off Mode Blue
Amber
Off
Specifications
DTV -Timing
Preset mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
*1
*2
*3
*4
5
6
720 x 480/60p
720 x 480/60p
1280 x 720/60p
1280 x 720/60p
1920 x 1080/60i
1920 x 1080/60i 31.47
31.5
44.96
45
33.72
33.75 60
60
60
60
60
60
* : User have to select directness PC or DTV
when using the PC or the Set-top box this resolution.
Preset mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Preset mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
1
2
3
4
5
6
7
8
9
10
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1152 x 864
1280 x 1024
1280 x 1024 31.468
31.469
37.500
37.879
46.875
48.363
60.123
67.500
63.981
79.976 70
60
75
60
75
60
75
75
60
75 11
12
13 1440 x 900
1440 x 900
1440 x 900 55.5
55.935
70.635 60
60
75
* 1~13 : RGB mode * 1~12 : HDMI mode
PC Mode – Preset Mode
