Configuration: How to Configure the System
Symmetra MW with External Bypass Static Switch Operation Manual - 990-1377D-001 19
Note: The APC Remote Monitoring Service (RMS) will not be activated until the RMS Team
has been contacted. The contact details can be found at http://rms.apc.com.
– Enable APC RMS: Select this checkbox to start using the service. Once selected, information
about your UPS will periodically be sent to APC’s Remote Monitoring Service.
– Use Proxy: Select this checkbox if the Internet connection method uses a HTTP proxy server to
connect to the Internet.
– Proxy server address: Enter the fully qualified IP-address or fully qualified domain name of the
proxy server. If you do not know the server address or port number, contact your network
administrator.
– Proxy server port: Enter the port number of the proxy server.
– Use authentication: Select this checkbox if the proxy server requires a login. Then specify a
Proxy server login (user name) and a Proxy server password.
– Press Apply Changes to complete the changes and select arrow down to go to the next Network
Configuration screen.
 Configure the APC ISX Manager Settings screen:
– Enable ISX manager discovery: Press the field
to enable the APC ISX Manager to discover
your Symmetra MW.
– Community name: Specify a valid community
name. This is automatically set to public.
– System location (optional).
– System contact (optional).
– Press Apply Changes to complete the
changes.
How to configure the Display Settings
 Press the Display Settings button on the User
Configuration screen to access the Display
Settings screen.
