APC SYMMETRA 990 - Manual (Page 21)

Configuration: How to Configure the System
Symmetra MW with External Bypass Static Switch Operation Manual - 990-1377D-001 17
 Configure the Network Settings screen:
– Enable network: Use this checkbox to connect
or disconnect the UPS from the network.
– IP Settings
• IP address: The static IP address.
• Subnet mask: The subnet mask for the
network segment containing the UPS.
• Gateway: The network gateway for the
segment containing the UPS.
– DNS Settings
• Primary DNS server: The IP address of the DNS server to be used by the UPS (optional).
• Secondary DNS server: The IP address of a backup DNS server if the primary server is not
available (optional).
– Host Name Settings
• Host name: The network host name for the system. This uniquely identifies the system on the
network. Standard letters (a-z and A-Z), digits (1-9), and hyphen (-) can be used.
• Domain name: The DNS network domain containing the UPS. Standard letters (a-z and A-Z),
digits (1-9), and hyphen (-) can be used.
– SMTP Settings
• From address: The source address used when sending e-mails.
• SMTP server: The SMTP server responsible for sending e-mails.
– Press Apply Changes to complete the changes and select arrow down to go to the next Network
Configuration screen.
Note: The display will have to be rebooted in order for the changes to the domain name or
DNS servers to take effect.
 Configure the E-mail Settings screen:
– Enable E-mail: Select to enable the e-mail
notifications.
– To add a new e-mail recipient, touch the Add
New button, type in the e-mail address and
specify the minimum severity of alarm. All
entries will appear in red until Apply Changes
is pressed.
– To edit or delete an e-mail recipient, select the
recipient from the recipient list, and then
choose to either update or delete it.
