80
APPENDIX
APPENDIX
2 22 2.. A Ab bnno orrm maall SSttaattee ((C Co om mm maannd d2 2::zz))
To recognize an abnormal state.
Data FF: Read
Data 0: Normal (Power on and signal exist)
Data 1: No signal (Power on)
Data 2: Turn the TV off by remote control
Data 3: Turn the TV off by sleep time function
Data 4: Turn the TV off by RS-232C function
Data 5: 5V down
Data 6: AC down
Data 7: Turn the TV off by Fan Alarm function (option)
Data 8: Turn the TV off by Off time function
Data 9: Turn the TV off by Auto sleep function
Data a: Turn the TV off by AV borad detect
* This function is “read only”.
Transmission [k][z][ ][Set ID][ ][FF][ ][Cr]
Acknowledgement [z][ ][Set ID][ ][OK][Data][x]
2 26 6 .. A Auutto o C Co onnffiigguurree ((C Co om mm maannd d1 1::jj,, C Co om mm maannd d2 2::uu))
To adjust picture position and minimize image
shaking automatically. It works only in RGB (PC)
mode.
Data 1: To set
Transmission [j][u][ ][Set ID][ ][Data][Cr]
Acknowledgement [u][ ][Set ID][ ][OK][Data][x]
MSB LSB
0 0 0 0 0 0 0 0
External Input Data
0 0 0 1 Analog
0 0 1 0 AV
0 1 0 0 Component
0 1 0 1 RGB-DTV
0 1 1 0 RGB-PC
1 0 0 1 HDMI
External Input Input Number
Acknowledgement [b][ ][Set ID][ ][OK][Data][x]
2 25 5.. K Keeyy ((C Co om mm maannd d1 1::m m,, C Co om mm maannd d2 2::cc))
To send IR remote key code.
Data: Key code - Refer to page 83.
Transmission [m][c][ ][Set ID][ ][Data][Cr]
Acknowledgement [c][ ][Set ID][ ][OK][Data][x]
2 24 4.. C Chhaannnneell A Ad dd d//D Deell ((C Co om mm maannd d1 1::m m,, C Co om mm maannd d2 2::b b))
To add and delete the channels
Data 0: Erase Data 1: Memory
Transmission [m][b][ ][Set ID][ ][Data][Cr]
Acknowledgement [b][ ][Set ID][ ][OK][Data][x]
Acknowledgement [a][ ][Set ID][ ][OK][Data0][Data1]
[Data2][Data3][Data4][Data5][x]
2 27 7.. IInnp puutt sseelleecctt ((C Co om mm maannd d1 1::xx,, C Co om mm maannd d2 2::b b))
((M Maaiinn PPiiccttuurree IInnp puutt))
To select input source for TV.
Data: Structure
Transmission [x][b][ ][Set ID][ ][Data][Cr]
2 23 3 .. C Chhaannnneell T Tuunniinngg ((C Co om mm maannd d1 1::m m,, C Co om mm maannd d2 2::aa))
Tune channel to following physical number.
Data 0: NTSC air : 02 ~ 45
NTSC cable : 01, 0E ~ 7D
Data 1 ~ 4: Don’t care
Data 5: High -> Main channel: 0, Sub channel: 8
Low -> Air: 0, CATV: 1
Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1][ ]
[Data2][ ][Data3][ ][Data4][ ][Data5][Cr]
2 21 1.. B Blluuee A Ad djjuussttm meenntt ((C Co om mm maannd d2 2::$ $))
To adjust blue in color temperature.
Data Min: 0 ~ Max: 50
Refer to ‘Real data mapping 2’. See page 81.
Transmission [k][$][ ][Set ID][ ][Data][Cr]
Acknowledgement [$][ ][Set ID][ ][OK][Data][x]
Input Number Data
0 0 0 0 Input1
0 0 0 1 Input2
