Appendix – LG 37LC2RR User Manual
Page 80
78
APPENDIX
APPENDIX
0
01
1.. P
Po
ow
weerr ((C
Co
om
mm
maan
nd
d2
2::aa))
To control Power On/Off of the TV.
Data 0 : Power Off
Data 1 : Power On
Transmission [k][a][ ][Set ID][ ][Data][Cr]
Acknowledgement [a][ ][Set ID][ ][OK][Data][x]
To show Power On/Off.
Transmission [k][a][ ][Set ID][ ][FF][Cr]
* In a like manner, if other functions transmit ‘FF’
data based on this format, Acknowledgement data
feedback presents status about each function.
* To change the Power on input the transmission
more than twice.
Acknowledgement [a][ ][Set ID][ ][OK][Data][x]
0
02
2.. A
Assp
peecctt R
Raattiio
o ((C
Co
om
mm
maannd
d2
2::cc)) ((M
Maaiinn p
piiccttuurree ssiizzee))
To adjust the screen format. (Main picture format)
You can also adjust the screen format using the ARC
(Aspect Ratio Control) button on remote control or
in the Screen menu.
Date 1: Normal screen (4:3)
Date 2: Wide screen (16:9)
Date 3: Horizon
Date 4: Zoom1
Date 5: Zoom2
Transmission [k][c][ ][Set ID][ ][Data][Cr]
Acknowledgement [c][ ][Set ID][ ][OK][Data][x]
* Using the RGB-PC, RGB-DTV, Component or HDMI
input, you select either 16:9 or 4:3 screen aspect
ratio.
0
03
3.. SSccrreeeenn M
Muuttee ((C
Co
om
mm
maannd
d2
2::d
d))
To select screen mute on/off.
Data 0 : Screen mute off (Picture on)
Data 1 : Screen mute on (Picture off)
Transmission [k][d][ ][Set ID][ ][Data][Cr]
Acknowledgement [d][ ][Set ID][ ][OK][Data][x]
0
04
4.. V
Vo
olluum
mee M
Muuttee ((C
Co
om
mm
maannd
d2
2::ee))
To control volume mute on/off.
You can also adjust mute using the MUTE button on
remote control.
Data 0 : Volume mute on (Volume off)
Data 1 : Volume mute off (Volume on)
Transmission [k][e][ ][Set ID][ ][Data][Cr]
Acknowledgement [e][ ][Set ID][ ][OK][Data][x]
0
05
5.. V
Vo
olluum
mee C
Co
onnttrro
oll ((C
Co
om
mm
maannd
d2
2::ff))
To adjust volume.
You can also adjust volume with the volume buttons
on remote control.
Data Min : 0 ~ Max : 64
Refer to ‘Real data mapping 1 ’. See page 81.
Transmission [k][f][ ][Set ID][ ][Data][Cr]
Acknowledgement [f][ ][Set ID][ ][OK][Data][x]
0
06
6.. C
Co
onnttrraasstt ((C
Co
om
mm
maannd
d2
2::gg))
To adjust screen contrast.
You can also adjust contrast in the Picture menu.
Data Min : 0 ~ Max : 64
Refer to ‘Real data mapping 1’. See page 81.
Transmission [k][g][ ][Set ID][ ][Data][Cr]
Acknowledgement [g][ ][Set ID][ ][OK][Data][x]
0
07
7.. B
Brriigghhttnneessss ((C
Co
om
mm
maannd
d2
2::hh))
To adjust screen brightness.
You can also adjust brightness in the Picture menu.
Data Min : 0 ~ Max : 64
Refer to ‘Real data mapping 1’. See page 81.
Transmission [k][h][ ][Set ID][ ][Data][Cr]
Acknowledgement [h][ ][Set ID][ ][OK][Data][x]
0
08
8.. C
Co
ollo
orr ((C
Co
om
mm
maannd
d2
2::ii))
To adjust the screen color.
You can also adjust color in the Picture menu.
Data Min : 0 ~ Max : 64
Refer to ‘Real data mapping 1’. See page 81.
Transmission [k][i][ ][Set ID][ ][Data][Cr]
Acknowledgement [i][ ][Set ID][ ][OK][Data][x]
0
09
9.. T
Tiinntt ((C
Co
om
mm
maannd
d2
2::jj))
To adjust the screen tint.
You can also adjust tint in the Picture menu.
Data Red : 0 ~ Green : 64
Refer to ‘Real data mapping 1’. See page 81.
Transmission [k][j][ ][Set ID][ ][Data][Cr]
Acknowledgement [j][ ][Set ID][ ][OK][Data][x]
