SPEC SHEET

Web Site: www.adc.com

From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080

Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our web site.

ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer

Specifications

ELECTRICAL
Insertion Loss

Better than -.5 dB, 100 KHz to 100 MHz

Better than -.8 dB, 100 MHz to 300 MHz

Return Loss:

Better than -20 dB, 100 KHz to 300 MHz

Monitor Loading Effect:

< .4 dB change in insertion loss to 300 MHz

Monitor Level:

21.5 ± 1.5 dB, 100 KHz to 300 MHz

Isolation:

< -55 dB at 22.368 MHz

Cross Talk:

< -55 dB at 22.368 MHz

Phase Delay

< 4 nanoseconds to 300 MHz

Pulse Template:

Conform to CCITT Recomm. G.703

MECHANICAL
Retention Force:

7 lbs. minimum

Retention Torque:

4" per lbs. minimum

ENVIRONMENTAL
Thermal Shock:

-40ºC to +60ºC operating

-55ºC to +85ºC non-operating

Moisture Resistance:

0% to 95%
