Sensor Bracket Assemblies
Illus. No. Part No. Qty. Description
1 880251 1 1/4” Temperature Sensor Probe Assembly
(includes illus. nos. 1 and 5 through 8)
2 130103 1 225º Large Automatic Reset Thermostat
3 153010 2 #6 Star Washer
4 152000 2 #6-32 Hex Nut
5 121028 2 Insulated Terminal
6 122701 4 Socket Terminal
7 122605 1 4-Pin Socket Connector
8 154007 2 1/4” Tinnerman Push On Fastener
9 150005 2 #6-32 x 1/4” Phillips Round Head Machine Screw
10 801425 1 Microprocessor Sensor Bracket Assembly Complete
(includes illus. nos. 1 through 10)
11 122604 1 4-Pin Connector ONLY
12 122700 4 Pin Terminal ONLY
13 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
14 150005 * #6-32 x 1/4” Phillips Round Head Machine Screw
15 130103 1 225º Large Automatic Reset Thermostat
16 130111 1 150º Large Thermostat
17 130100 1 130º Large Thermostat
18 130101 1 180º Large Thermostat
19 153010 * #6 Star Washer
20 152000 * #6-32 Hex Nut
21 121028 ** Insulated Terminal
22 840065 1 Sensor Jumper (4)
23 122701 *** Socket Terminal
24 122605 1 4-Pin Socket Connector ONLY
840062 1 Sensor (4) Bracket Harness Assembly
(includes illus. nos. 21, 23, and 24)
25 801418 1 Noncomputer Sensor (4) Bracket Harness Assembly Complete
(includes thermostats)
(includes illus. nos. 14 through 27)
26 122604 1 4-Pin Connector ONLY
27 122700 *** Pin Terminal ONLY
122801 1 Pin/Socket Extraction Tool
28 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
* Qty. = 4 or 5.
** Qty. = 6 or 8.
*** Qty. = 3 or 4.
