Slide meter case assembly – American Dryer Corp. AD-24 II User Manual
Page 11
9
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
1
160099
1
Lock/Key/Cam and Hardware
160199*
1
Key ONLY for Slide Meter Lock
2
125908
1
Slide Meter Accumulator - 24 VAC - 60 RPM (60 Hz Only)
3
122643
9
Mate-N-Lock Pin ONLY
4
122642
1
9-Position Mini-Universal Socket
5
152014
4
1/4-20 Free Spin Wash Nut
6
122603
1
9-Position Connector (Mate-N-Lock)
7
122631
2
6-Position Connector (Mate-N-Lock)
8
881100
1
Slide Meter Modular J-Box Assembly
9
122701
21
Socket Terminal ONLY
10
125900
1
Slide Meter Case with Door Less Lock
11
154001
2
#10-24 Speed Nut
12
150300
4
#10-16 x 1/2” Hex Washer TEK Screw
13
881015
1
Slide Meter Control Panel (faceplate) Complete
(includes illus. nos. 11 and 13 through 16)
880937
1
Slide Meter Control Panel (faceplate) ONLY
14
122400
1
Rocker Heat Selector Switch
15
131917
1
Push-to-Start Relay - 24 VAC
16
123005
1
Red Light Indicator - 24 VAC
17
125903
1
Slide Meter Extension
18
--------
1
Typical Slide Meter Coin Chute (not available from ADC)
19
--------
1
Typical Slide Meter Coin Box (not available from ADC)
20
801701
1
Slide Meter Case Mounting Plate
21
102502
1
Control Door Support Rod
22
102601
1
Control Door Rod Retainer Clip
23
102603
1
Control Door Support Rod Catch
24
150207
2
#10-24 x 1/2” Round Head Machine Screw
*
Specify key number when ordering.
Slide Meter Case Assembly
