2 System tour 10
Item Description
BT1 Battery
CN2 ATX power connector (20 pin)
CN3 ATX power connector (4 pin)
CN6
CN7
CN9
Fan connectors
CN19 Front Panel connector
CN21 CD-ROM power connector
CN23 ARMC Feature connector
CN25 Add-on card HDD LED connector
CN29 LPC debug card interface connector
COM1 Serial port
DIMM1
DIMM2
DIMM3
DIMM4
DIMM slots
FDD Floppy disc drive connector
JP1 Clear CMOS
JP2 Password
JP4 Boot Block
KM1 PS/2 Mouse/Keyboard ports
LAN1
LAN2
Gigabit Ethernet ports
LED1 Rear panel ID indicator
PCIX2 PCI riser slot
