Page 5
English 3
Installation Instructions
Appliance and Cabinet Cutout Dimensions
Steam Oven Installation Dimensions
22
3
/
8
"
(568)
13
3
/
4
"
(350)
19"
(483)
29
3
/
4
"
(755)
19
5
/
8
"
(498)
48"
(1220)
27
13
/
16
"
(706)
21
3
/
8
"
(543)
24
1
/
2
"
(622)
Appliance Dimensions
Cabinet Dimensions
min. 4
3
/
4
"-
max. 42"
(121-1067)
* Receptacle may be
located above or
beneath the unit
within reach of the
power cord.
*
*
19
1
/
4
"
(488)
28
1
/
2
"
(724)
23½"
(597)
Under Counter Dimensions
* Includes
3
/
4
" (19) base plate
** Receptacle may be located to the
left or right of the unit within reach
of the power cord.
**
* 4
3
/
4
"-13
3
/
4
"
(121-350)
23½"
(597)
3"
(76)
36"
(915)
28
1
/
2
"
(724)
19
1
/
4
"
(488)
Flush Mount Dimensions
*
Top View
Side View
reveal cleats
20
1
/
8
"
(511)
flush
cut-out
height
23
1
/
2
"
(597)
flush inset
depth
3
/
4
" (19)
reveal
cleats
3
/
4
" (19)
reveal
cleats
* Flush installation requires a 5/16"(8) high x 28½" (724) wide x 22½" (571) deep
baseplate underneath the unit body.
1"
(25)
1"
(25)
28
1
/
2
" (724)
30" (762)
23
1
/
2
"
(597)
All measurements in Inches (mm)
