LCD Inverter Connector (LCDB1)
For inverters with adjustable Backlight function, it is possible to control
the LCD brightness through the VR signal controlled by LCDPJ1.
Please see the LCDPJ1 section for detailed circuitry information.
z
Signal Description
Signal
Signal Description
VR
Vadj=0.75V ~ 4.25V
(Recommended: 4.7KΩ, > 1/16W)
TFTxBLKEN
LCD backlight ON/OFF control signal
1.6.14
LVDS Connector (LVDS1)
