NX800LX
16
Internal Connector
Label Function Note Page
CFPJ1 CF power connector 3 x 2 header, pitch 2.54mm 21
CN5 ATX power connector 3 x 2 header 21
CN7 Power fan connector 3 x 1 wafer, pitch 2.54mm 21
CN8 SM Bus connector 4 x 1 wafer, pitch 2.00mm 22
COMB1 Serial port 1 in RS-232 mode 5 x 2 header, pitch 2.00mm 22
COMB2 Serial port 2 in RS-232 mode 5 x 2 header, pitch 2.00mm 22
FPANEL1 Front panel connector 5 x 2 header, pitch 2.00mm 23
IRB1 IrDA connector 5 x 1 header, pitch 2.00mm, 24
IDEB1 Primary IDE connector 22 x 2 header, pitch 2.00mm 24
J1 AC97 line in connector 5 x 1 header, pitch 2.00mm 25
J2 GPIO connector 6 x 2 header, pitch 2.00mm 25
LCDB1 LCD inverter connector 5 x 1 header, pitch 2.00mm 26
LVDS1 LVDS connector HIROSE DF13-20DP-1.25V 26
TTL1 TTL connector HIROSE DF13-40DP-1.25V 27
USBB1 USB 2.0 connector 5 x 2 header, pitch 2.00mm 27
