P.6 Installation Guide CT-5000
12-Pin Accessories Harness
Wire Description
1
BLUE
(–) AUX 3
(Trunk)
output
500 mA negative output. This output can be used to control Trunk
release (1-sec. pulse) or can be set to operate as a constant output as
long as the
TRUNK button is held pressed. (For Sunroof or Window
close).
Note:
AUX3 ( TRUNK ) operates only when Ignition is OFF or when the
vehicle is running under remote control.
2
BROWN
(–) Lock
output
Programmable 500 mA, 1/10-sec., 7/10-sec. or 4-sec. negative output.
3
GREEN
(–) Unlock
output
Programmable 500 mA, 1/10-sec., 7/10-sec., 4-sec. or a double ¼-sec.
pulse negative output.
4
WHITE /
BROWN
(–) Arm
output
500 mA ground output when the LOCK button is pressed. This output is
activated 500 ms before the LOCK pulse and deactivated 250 ms after
the LOCK pulse ends.
Note: The system will also give an ARM/REARM pulse on this wire when it
shuts down the vehicle after a remote start.
5
WHITE /
GREEN
(–) Disarm
output
500 mA ground output when the UNLOCK button is pressed. This wire is
for disarming OEM Alarm systems.
Note: System will also give a
DISARM pulse before remote start.
6
BLUE /
WHITE
(+) Positive
Door input
This input should be used in vehicles that use a positive-switching
Dome Light circuit. Connect to a Dome Light wire testing +12 V with a
Door open.
CAUTION! You can only use a negative or a positive connection. In
other words, only the NEGATIVE DOOR INPUT or the POSITIVE
DOOR INPUT wire is connected. It is essential that the Module be
connected in such a way as to allow each one of the Doors to turn off
Ready Mode: the driver-side Door Pin does not constitute by itself a
sufficient connection
7
WHITE /
ORANGE
(–) Starter
Kill output
The unit is equipped with a selectable passive- or active-arming
Starter Kill circuit that will immobilize the vehicle when the system is
armed. This wire will provide a constant 500-mA negative output when
the system is armed (locked by remote) or if remote started. This wire
should be connected to a Single Pole Double-Throw Relay (This wire
will connect to Pin 85, on the Relay, and Pin 86 will be connected to the
Ignition wire).
A second benefit of the Starter Kill is the Anti-Grind feature. When the
vehicle has been remote started the Anti-Grind prevents the starter
motor from re-engaging when the ignition key is inserted in the Ignition
switch and accidentally turned to the
CRANK position (The Starter Kill
output becomes active during remote starts).
8
ORANGE
N/A
N/A
9
PURPLE
(+) Siren or
Horn output
+12 V Siren output. Connect to the positive side of the Siren or the can
be used for OEM Horn Honk control (a relay may be needed).
