CT-5000 Installation Guide P.29
Diagnostics - Parking Lights Flash Rate
Flashes Description
1
• Doors locked, Starter Kill armed.
• End of Run Time.
• TRUNK button pressed
• START signal received by the Module.
• Cold Weather Mode cancelled.
• Cannot start after maximum number of attempts is reached.
2
• Run Time cancelled.
• Remote start attempt cancelled by remote.
• Doors unlocked, Starter Kill disarmed.
• Exit remote valet
• Exit ignition valet
3
• Entering Cold Weather Mode
• Enter remote valet
• Enter ignition valet
4
• +12 volts detected on the Brake line; cranking cancelled
• Entering Tach Learning
5
• New Transmitter learnt
• Tach learnt
6
• Remote start attempt was made with a Tach or a vacuum signal detected before
cranking
8 • Unit reset: occurs when the unit is reset to factory defaults
10 • The Hood Switch line went to ground during cranking or run time
1 – pause –
2
• There was an attempt to start the vehicle while the Module was in Valet Mode.
2 – pause –
2
• There was an attempt to start the vehicle while the Module was in Home Valet
Mode.
ON solid • Cold Weather Mode: the Brake Pedal is being held down
ON 2 sec.
• The Hood is up and the Hood Switch line went to ground. This is step one of the
Programming Mode
ON 3 sec.
• First press of the START/STOP button under Safe Start.
• Entering Home Valet Mode
ON 4 sec. • LOCK or UNLOCK pulse (if door pulse is configured to 4 sec.)
ON 25 sec.
• If the Hood Pin-switch has been pressed twice: the Unit went into step 1 of the
Programming cycle and no Transmitter activity was detected for 20 seconds
• Or the Unit went into step 1 of the Transmitter Code Learning procedure and no
activity was detected for a few seconds. The Unit has exited the Transmitter Code
Learning procedure.
Irregular
• If the Module gives irregular flashes (1 to 10 flashes followed by a pause, followed
by more flashes), it is in Playback Mode. This occurs when the Hood-switch line is
flashed 3 times.
Constant
flashes
up to 30 sec.
• Panic Mode set off.
