Fixing the Plug to the Camera
Fasten the plug to the camera with the cable protector to prevent it from
detaching during remote shooting.
1 Open the cover, and connect the small plug of the
cable to the camera’s terminal.
 Check the direction of the < > mark on the plug and push it
in.
2 Attach the cable protector in the order (1), (2).
1D X 1D C 1D Mk IV 1Ds Mk III 1D Mk III
1D X 1D C
Cable protector
(1)
(2)
Cable protector attached.
3 Remove the cable protector in the order (1), (2).
(1)
(2)
