Page B-2
FS7000 Series Physical and Environmental Specifications
AC Inputs 100–240 volts AC, 50/60 Hz (internal universal power supply)
Power
Consumption 15–30 watts (depends on model/configuration)
Operating
Temperature 32
°
to 104
°
F (0
°
to 40
°
C)
Storage
Temperature -4 ° to 158 ° F (-20 ° to 70 ° C)
Humidity 10% to 90% non-condensing
Dimensions FS7108: 17.3 in wide x 9.9 in deep x 1.7 in high (440 x 253 x 43.2 mm)
FS7x16: 17.3 in wide x 9.9 in deep x 2.6 in high (440 x 253 x 64.8 mm)
Weight
(Shipping) FS7108: 8 lbs (3.6 Kg)
FS7016: 10 lbs (4.5 Kg)
EMI FCC Class A, CE Class A, VCCI A
Safety CE, UL, TUV, CUL
FS7000 Series Performance Specifications
Transmission
Method Store-and-forward
RAM Buffer 4MB per device
Filtering
Address Table 12K entries per device
Packet Filtering/
Forwarding Rate 10Mbps: 14,880pps per port
100Mbps: 148,800pps per port
