27
STEP
1
STEP
2
STEP
3
STEP
4
Getting started
Refer
ence
Label Over
view
In
troduction
For W
indows
®
Fo
r Macintosh
®
Insta
lling the
Softwar
e
Reference
„ Product specifications
„ Operating environment
*1 The computer should meet Microsoft
®
's recommendations for the OS installed.
*2 Required available space when installing the software with all of the options.
*3 The RS-232C interface is required when printing with ESC/P commands.
Items Specifications
Display LED lamp (green, red, orange)
Print
Printing method Direct thermal printing via thermal head
Speed of printing
Max. 4.3 inch (110 mm)/sec, Max. 69 labels/min. (Standard
Address Labels) (When connecting USB cable)
Print head 300 dpi/1296 dot
Max. printing width 3.9 inch (98.6 mm)
Min. printing length 1 inch (25.4 mm)
Cutter Durable automatic cutter
Button ON/OFF button ( ), FEED button, CUT button
Interface USB, Serial (RS-232C), 10/100BASE-TX Wired Ethernet
Power supply 120V AC 60 Hz 1.8 A
Size 6.6" (170 mm) × 8.6" (220 mm) × 5.8" (147.5 mm)
Weight Approx. 3.8 lb (1.73 kg) (Without DK Rolls)
Items Specifications
OS
Windows
®
Windows
®
2000 Professional/XP/Windows Vista
®
/
Windows Server
®
2003
*1
Macintosh ® Mac OS ® X 10.3.9 ~ 10.4.10
Interface
Windows
®
Serial (RS-232C)
*3
, USB port (USB Spec. 1.1 or 2.0 protocol),
10/100BASE-TX Wired Ethernet
Macintosh
®
USB port (USB Spec. 1.1 or 2.0 protocol), 10/100BASE-TX Wired
Ethernet
Hard
Disk
Windows
®
Disk space more than 70 MB
*2
Macintosh
®
Disk space more than 100 MB
*2
Memory
Windows
®
Windows
®
2000 Professional/XP: More than 128 MB
Windows Vista
®
: More than 512 MB
Macintosh ® More than 128 MB
Monitor
Windows
®
SVGA, high color or higher graphics card
Macintosh
®
More than 256 colors
Others CD-ROM drive
Operating temperature 50°F to 95 °F (10°C to 35°C)
Operating humidity 20% to 80% (without condensation)
Main Specifications
