Removal
1. Remove the detachable front panel.
2. Insert the bracket keys into the unit, along the guides
on either side. The unit can now be removed from the
mounting sleeve.
3. Pull the unit out, keeping it unlocked as you do so.
• Secure the ground lead of the unit to a clean metal spot using a
screw (*
3
) already attached to the vehicle's chassis.
This unit
Bracket keys
(Included)
Face Plate
Screws (M5 × 8)
(Included)
Mounting Bracket
Ground Lead
this unit
*
3
