50’ NAVI-TRAC COMPLETE

WITH (2) 20’ MID BAYS

1. SIDEWALLS MUST BE ADDED TO COMPLETE THE UNIT (SEE BLUEPRINT INFORMATION).

2. INSTALL, STAKE, AND TENSION ALL GUY WEBS, AS SHOWN. TENSION FABRIC SO THAT

ALL CATENARY ARCHES ARE EQUIDISTANT BELOW THE EAVE BARS.

3. REVIEW PAGE 11 FOR GUYING AND TENSIONING INSTRUCTIONS.
