Installation Guide
QUICK START INSTALL
14 Pin Power Connector
Step 2- Plug-In The Module
Step 3- Program, Test And Adjust The Shock Sensor
Your Basic Install Is Complete!
Test The System
Step 1 - Connect All Of the Following Wires
Your Basic Installation is Now Complete!!
When all the connections are done, the control module can be plugged in. Before connecting the control
module, make sure the ignition is in the OFF position. Plug in the 6 pin harness then the 14 pin followed
by any other connectors that were used.
6
Black Ground Input System ground input.
Yellow Ignition Input Input from vehicles ignition wire.
Red Main Power Input Constant 12 Volt input.
Brown (+) Siren Output Positive output for siren.
White (+) Park lights Park light output. Programmable - menu 2, setting 3.
Green* (-) Door Input Negative door pin switch input.
Purple* (+) Door Input Positive door pin switch input.
*Test for door pin type (Positive or Negative) then connect the appropriate wire (Green or Purple)
To program the Shock Sensor.
1. Press and release Lock button Five times.
2. The system will chirp and the park lights will flash three times then stay “ON”.
3. Within 10 seconds impact vehicle in a safe place (i.e. - Window pillar) with amount of force wanted to
activate alarm. The siren will chirp upon learning the impact.
4. The Shock Sensor is now programmed.
5. Press the Unlock button to exit the Program Mode.
To test the Shock Sensor.
1. Press the Lock button once to arm the system.
2. Wait five seconds then impact the vehicle. Lighter impacts to the vehicle should trigger the warn away
(The siren will chirp three times). A harder impact to the vehicle will trigger the full alarm.(The siren will
activate for 60 seconds then turn off).
3. To deactivate the alarm when triggered, press the unlock button twice.
To adjust the Shock Sensor.
1. Repeat the shock sensor learning.
- If the sensor was to sensitive, impact the vehicle with less force.
- If the sensor was not sensitive enough, impact the vehicle with greater force.
*For best results ensure that the Control Module is mounted securely to the vehicle.
1. Open all the vehicles windows.
2. Press the Lock button to arm the system.
3. Wait five seconds (or until the dome light goes out) then reach in through a window and open the door.
The alarm will then activate (repeat on all the doors).
4. Test the Shock Sensor again and adjust if necessary.
5. Insure that all additional features are working as intended.
6. If necessary proceed to Program Mode to adjust the programmable outputs.
