Installation Guide

DIAGNOSTICS

12

If the alarm system is triggered while armed, the system will retain in memory the cause of the trigger. The
diagnostics can then be used to determine what the cause of the trigger was. When disarming the alarm,
the siren/horn will chirp 3 times instead of the usual 2 times to indicate the alarm had been triggered.
The system’s LED will also flash in pulses to indicate which input triggered the alarm.

NOTE: LED status will be cleared when ignition is turned ON. For proper memory clearing, insure to
connect the ignition input to the ignition on the vehicle

Note: While the system is disarmed and the ignition is in the off position, the LED will activate from the
following triggers.

1) The door is opened. The LED will Stay on until the door is closed.
2) The hood is opened. The LED will stay on until the hood is closed.
3) The Shock Senor. The LED will flash when impact is detected.
4) The Aux Sensor. The LED will flash when the input is triggered.

Alarm Diagnostics

Additional LED Flashes

Park Light Flashes

LED Flashes

Diagnostic

Two Flashes

Two Flashes

Shock Sensor Triggered

Three Flashes

Three Flashes

Door Input Triggered

Four Flashes

Four Flashes

Ignition Input Triggered

Five Flashes

Five Flashes

Hood Input Triggered

None

Off

System Disarmed

None

On Solid

Valet Mode

None

Single Flashes

System Armed

None

Rapid Flashes

Passive Arming
