Raster Command Reference

- 44 -

5. Flow Charts

5.10 Buffered printing normal flow for network (standard TCP/IP port) connection

※

With a network connection, print data from the operating system’s port monitor is sent as is.

The following example is for printing 2 pages.

BUSY

Computer（host）

Printer

The print data is divided
into a specific size and
sent.

Data received

Printing 1nd page

Data for 1st page to here

Sending data for 2nd page

Sending raster data

Printing 2nd page

Printing begins since
the data for the first
page was received.

Printing begins since
the data for the
second page was
received.

Since transmission of the
print data was completed,
the job is erased from the
computer.
Printing is considered by
the computer to be
completed.

Printer buffer is
full.
