Raster Command Reference
- 19 -
2. Print Data
Die-cut labels:
TD-2020/2120N
Label Size
Number of Pins
for Left Margin
Number of Print
Area Pins
Number of Pins
for Right Margin
Number of Bytes for
Raster Graphics Transfer
51 mm x 26 mm 33 382 33 56
30 mm x 30 mm 116 216 116 56
40 mm x 40 mm 76 296 76 56
40 mm x 50 mm 76 296 76 56
40 mm x 60 mm 76 296 76 56
50 mm x 30mm 36 376 36 56
60mm x 60mm 0 448 0 56
TD-2130N
Label Size
Number of Pins
for Left Margin
Number of Print
Area Pins
Number of Pins
for Right Margin
Number of Bytes for
Raster Graphics Transfer
51 mm x 26 mm 54 564 54 84
30 mm x 30 mm 177 318 177 84
40 mm x 40 mm 118 436 118 84
40 mm x 50 mm 118 436 118 84
40 mm x 60 mm 118 436 118 84
50 mm x 30mm 59 554 59 84
60 mm x 60mm 6 660 6 84
