Raster Command Reference
- 30 -
4. Printing Command Details
ESC i M
Various mode settings
ASCII:
ESC
i
M
{n1}
Hexadecimal: 1B
69
4D
{n1}
Parameters
Definitions of {n1}
The meaning of each bit in a 1-byte parameter is described below.
0 ～ 2bit：Not used
3bit：Inverted 180 Degrees 1. Rotates 180 degrees 0. Does not rotate 180 degrees
4bit：Peeler Function 1. Uses the peeler function 0. Does not use the peeler function
5 ～ 7bit：Not used
ESC i d
Specify margin amount (feed amount)
ASCII:
ESC
i
d
{n1}
{n2}
Hexadecimal: 1B
69
64
{n1}
{n2}
Description
Specifies the amount of the margins.
Margin amount (dots)=n1+n2*256
With die-cut labels, the margin amount at the ends of the printed area is 0.
(a) Continuous length tape
Print area
Margin amount
Tape
Paper
Cut line
(b) Die-cut labels
Margin amount
(only
“0” is available)
Print area
Label
Paper
Cut line
