Raster Command Reference
- 13 -
2. Print Data
2.3.2 Page size
(a) Continuous length tape
Feeding direction
6
5
Landscape
3 1
4
2
Print area
6
5
3
1
4
2
P o r t r a i t
Feedin
g dir
ect
ion
P r i n t
a r e a
Number 1 Width 2 Length
3 Print area width (maximum printing width) 4 Print area length
5 Width offset 6 Length offset
203dpi×203dpi
ID Tape Size Designation 1 2 3 4 5 6
438 57 mm
57 mm
2.25"
57.2 mm
457 dots
--> 2.3.4.
54.1 mm
432 dots
--> 2.3.4.
1.5 mm
12 dots
--> 2.3.3.
426 58 mm
58 mm
2.28 ”
58.0 mm
464 dots
--> 2.3.4.
55.1 mm
440 dots
--> 2.3.4.
1.5 mm
12 dots
--> 2.3.3.
300dpi×300dpi
ID Tape Size Designation 1 2 3 4 5 6
438 57 mm
57 mm
2.25"
57.2 mm
675 dots
--> 2.3.4.
54.0 mm
638 dots
--> 2.3.4.
1.5 mm
18 dots
--> 2.3.3.
426 58 mm
58 mm
2.28 ”
58.0 mm
685 dots
--> 2.3.4.
54.9 mm
648 dots
--> 2.3.4.
1.5 mm
18 dots
--> 2.3.3.
