Trio Motion Technology MC405 - Manual

(Please refer to the Motion Coordinator Technical Reference Manual for Full Details)
MOTION COORDINATOR
MC405
Quick Connection Guide
CAN PORT FOR TRIOCAN
I/O, DEVICENET SLAVE,
CANOPEN OR USER
PROGRAMMABLE
8 INPUTS INCLUDING
8 REGISTRATION INPUTS
8 BI-DIRECTIONAL I/O
2 ANALOGUE INPUTS AND
4 ANALOGUE OUTPUTS,
WDOG RELAY
LED DISPLAY AND
STATUS LED’S
AY AND
LED’S
5 ENCODER CONNECTIONS
(6MHZ) OR DRIVE AS
STEPPER OUTPUT (2MHZ)
MICRO SD CARD
RS232 / RS485
MODBUS-RTU,
HOSTLINK OR USER
PROGRAMMABLE
MOTION
ETHERNET
PROGRAMMING, MODBUS-
TCP, ETHERNET IP
PANEL MOUNT AND DIN
RAIL MOUNT
