Sterlco SMS Series Single Shaft Shredder User Manual
Page 87
GRN4-605
0Appendix
87 of 93
Model 2000
Pos.
Pc
Description/Standard
100
Machine complete
101
1
Standard hopper
102
2
PP-scraper side
103
1
PP-scraper top
104
1
Upper door
105
1
Lower door
106
2
Safety grid side
107
1
Safety grid back
108
1
Safety grid back
109
1
Ram residual chute
200
Screen complete (Hydraulic)
201
1
Screen 12/16/20/25
202
8
Screen support screws DIN912-M12x35-8.8
203
8
Washer DIN125-B-13-140HV
204
8
Spring washer DIN127-A-13
205
1
Screen support
206
2
Cylinder for screen support opening
Ø50xØ25x145
300
Bearing
301
2
Bearing housing SN324/16Mn
302
2
Bearing GB/T288-94/22324
303
1
Bearing Cover A
304
3
Bearing Cover B
305
0
306
4
Sealing GB9877.1-86 J150x180x15
307
2
Grease nipple GB1152-89/M8x1
308
2
Sleeve Ø150x16
309
32
Mounting screw cover plate
DIN912-M10x40-8.8
310
2
Bearing mounting plate
311
4
Mounting plate screw DIN912 – M12x70 –
12.9
400
Drive
401
1
1
Motor 55 kW 460V/60HZ (right)
Motor 55 kW 460V/60HZ (left)
1
Motor 75 kW 460V/60HZ (right)
1
Motor 75 kW 460V/60HZ (left)
402
2
Gear pulley SPC300-4
403
2
Gear pulley taper bushing TB 3535-50
Gear pulley taper bushing TB 3535-55
404
2
Key C25x210
405
8
V-Belt SPC 2430
V-Belt SPC 2550
406
2
Motor pulley SPC 250-4
Motor pulley SPC 300-4
407
2
Motor pulley taper bushing 3535-65
Motor pulley taper bushing 3535-75
408
2
Key Motor shaft
409
2
Pulley cover
410
2
Motor plate
411
2
Gear box MC2PLHT03 i=20
412
2
Torque arm plate 55KW
