Sterlco SMS Series Single Shaft Shredder User Manual
Page 81
GRN4-605
0Appendix
81 of 93
Model 1200
Pos.
Pc
Description/Standard
101
1
Standard hopper
102
2
PP-scraper side
103
1
PP-scraper top
104
1
Upper door
105
1
Lower door
106
2
Safety grid side
107
1
Safety grid back
108
1
Safety grid back
109
1
Ram residual chute
200
Screen complete (Standard)
201
1
Screen
202
5
Screen support screw DIN912–M12x35–
8.8
203
5
Washer DIN125-B-13-140HV
204
5
Spring washer DIN127-A-13
205
2
Clamp
206
2
Clamp mounting screws DIN933 – M20 –
8.8
207
2
Washer DIN125-A – 20 – 140HV
208
2
Spring washer DIN127-A-20
200
1
Screen complete (Hydraulic)
201
1
Screen
202
5
Screen support screws DIN912-M12x35-
8.8
203
5
Washer DIN125-B-13-140HV
204
5
Spring washer DIN127-A-13
205
1
Screen support
206
2
Cylinder for screen support opening
Ø50xØ25x145
300
2
Bearing
301
2
Bearing housing SN324
302
2
Bearing GB/T288-94-22324
303
2
Bearing Cover A
304
1
Bearing Cover B
305
1
Bearing housing cover plate
306
3
Sealing GB9877.1-86 J150x180x15
307
2
Grease nipple GB1152-89/M8x1
308
2
Sleeve Ø150x16
309
24
Mounting screw cover plate
DIN912-M10x40-8.8
8
Mounting screw cover plate
DIN912-M10x45-8.8
310
1
Bearing mounting plate
311
1
Mounting plate screw DIN912 – M24x50 –
8.8
312
1
Washer DIN125 - A - 24
400
Drive
401
1
Motor 55 kW 460V/60Hz
Motor 75KW 460V/60Hz
402
1
Gear pulley SPC300-4
Gear pulley SPC375-4
403
1
Gear pulley taper bushing TB 3535-50
