Sterlco SMS Series Single Shaft Shredder User Manual
Page 79
GRN4-605
0Appendix
79 of 93
405
4
V-Belt SPB 2150
V-Belt SPC 2430
406
1
Motor pulley SPB 224-4
Motor pulley SPC 250-4
407
1
Motor pulley taper bushing TB 3020-60
Motor pulley taper bushing TB 3535-65
408
1
Key Motor shaft
409
1
Pulley cover
410
1
Motor plate
411
1
Gear box SEW MC2PLHT02 i=20
412
1
Torque arm plate
413
1
Rubber bushing plate
414
1
Rubber bushing
415
1
Copper bushing
416
1
Torque arm screw
417
1
Cover plate
500
1
E-knife rotor ø387x850
501
60
Rotor knife 34x34x20
502
60
Rotor knife mounting Screw
DIN912 – M12x40 – 12.9
503
60
Washer GB/T1230-13
504
60
Rotor knife holder
505
120
Knife holder mounting screw DIN912 – M8x25–
12.9
600
2
Bed knife complete
601
6
Bed knife 279x80x30
602
12
Mounting Screw DIN912 – M12x55 – 12.9
603
6
Lower bed knife adjusting screw for pushing
DIN912 – M16x35 – 12.9
604
6
Upper bed knife adjusting screw for pushing
DIN912 – M16x45 – 12.9
605
12
Bed knife adjusting screw for pulling
DIN912 – M16x50 – 12.9
606
1
Bed knife cover plate
1
Bed knife cover plate left
1
Bed knife cover plate right
607
12
Cover plate mounting screw DIN912–M12x35–
12.9
700
1
Ram complete
701
2
Arm for ram
702
2
Bearing for arm UCFC212
703
8
Mounting screw for bearing DIN912-M16x50-
12.9
704
2
Screw for arm
705
1
Ram
706
12
Mounting screws ram arm DIN912-M16x80-12.9
707
12
Nut DIN982 – M16 – 10
708
12
Washer DIN 433-16-300HV
709
12
Spring washer DIN127-A-16
710
12
Mounting pin DIN94-2.5x32
711
1
Scraper
712
4
Spring for scraper YI GB1356-78
n=12/d=2/D=12/H=60
713
1
Cover plate for scraper
714
2
Upper cylinder screw
715
2
Lower screw for cylinder mounting
