Chapter 2: Functional Description
22 of 93
Discharge of Shredding Material
Normally the shredded material will be discharged onto a conveyor belt. (Options
include a discharge with blower or with a screw conveyor.)
(1) Hydraulic cylinder
(2) Screen support
(3) Screen
3
2
1
Discharge with
conveyor
