GRN4-610 Chapter 7: Appendix 71 of 73
Pos. Pc Description/Standard Partnumber/SAP
700 1 Pusher complete
701 1 Stage cylinder 100x140x180x225-7000
702 6 Support roller NATV40PPA
703 6 Shaft for bearing ZRS1500-05-01-02-01
704 12 Lock washer DIN5406 – MB8
705 12 Slotted nut DIN981 – KM8
706 12 Fixing bolt support roller DIN933 – M16 –
12.9
707 12 Washer DIN125 – 16 – 300HV
708 18 Support roller KR80PPA
709 18 Nut DIN934 – M30x1.5 – 10
710 18 Washer DIN125 – 31 – 300HV
711 3 Scraper
712 1 Bolt for cylinder ZRS1500-12-03-00
800 Hydraulic
801 3 Cylinder for cover 63 x 35 x 280
802 1 Hydraulic unit SCH-412-00-2 F 15 kW
803 6 Pipe holder 80050784
804 Connectors
900 Electrical parts
901 3 Safety switch AZ15zvrk
902 5 Small control box
903 1 Control panel
904 1 Control cabinet
905 3 Proximity switch II0297
906 3 Cable for Proximity switch E10200
907 1 Laser distance sensor 01D1000
908 3 Light barrier YM-T10
