Sterlco SPS Series Pipe Shredder - Manual (Page 70)

GRN4-610 Chapter 7: Appendix 70 of 73
402 2 Gear pulley SPC375-4
403 2 Gear pulley taper bush TB 3535 - 48 80002370
404 2 Key
405 8 V-Belt SPC3350
406 2 Motor pulley SPC375-4
407 2 Motor pulley taper bush TB 3535 - 60 80002350
408 2 Key
409 2 Pulley cover + support ZRS1000-15-01-00
410 1 Base frame for motor ZRS1000-07-01-00
411
1 Gear box SEW MC3PLHF06SD – 14 (i=41)
1 Gear box SEW MC3PLHF05SD – 23 (i-41)
412 2 Torque arm plate ZRS1000-07-04-01-00
413 8 Bolt DIN933 – M24x140 – 12.9
414 16 Washer DIN433 – 25 – 300HV
415 8 Nut DIN934 – M24
416 2 Torque arm bolt ZRS1500-07-05
417 40 Disc spring DIN2093 – A71
418 2 Hard washer ZRS1000-07-06-04
419 2 Nut DIN934 – M36 – 10
420 2 Nut DIN935 – M36 – 10 80040180
421 6 Hard washer ZRS1000-07-06-06
422 2 Fixing bolt ZRS1500-07-03-00
423 2 Bolt DIN933 – M10x30 – 8.8
424 2 Washer DIN125 – A10
425 2 Spring washer DIN127 – 10
426 2 Distance sleeve ZRS1000-07-07
427 2 Cover ZRS1000-07-08
428 2 Bolt DIN933 – M16x45
429 2 Spring washer DIN127 - 17
500 1 E-knife rotor 1482x1410
501 204 Rotor knife 34x34x20 80001002
502 204 Rotor knife fixing Bolt DIN912 – M12x40 – 12.9 80040034
503 204 Washer GB/T1230-12 80040029
504 204 Rotor knife holder 21660700
505 408 Knife holder fixing bolt M8x25 DIN912/12.9 80011090
506 204 Underlay plate t=2 ZRS1500-06-01-05
600 1 Stator knife complete
601 4 Stator knife 279x80x30 80001202
602 8 Prism fixing Bolt DIN912 – M12x65 – 12.9
603 8 Bolt for pushing DIN912 – M12x65 – 12.9 80011290
604 8 Bolt for pulling DIN912 – M16x50 – 12.9
605 8 Knife holder fixing bolt DIN912 – M16x45 – 12.9 80011290
606 4 Knife holder plate ZRS1500-01-01-03-03
607 4 Prism ZRS1500-01-01-03-02
