Sterlco SPS Series Pipe Shredder - Manual (Page 61)

GRN4-610 Chapter 7: Appendix 61 of 73
Chapter 7: Appendix
7-1 Technical Specifications
Feeding chamber opening: Data in mm: 6720x840
Rotor dimension: Diameter in mm:
Width of cut in mm:
980
1210
Rotor type E
Rotor knives: No. of rotor knives: 108
Stator knives: No. of stator knives: 4
Rows of stator knives: 1x4
Rotor speed (50Hz): rpm 36
Width: Data in mm: 2820
Length: Data in mm: 11770
Height: Data in mm: 2590
Drive motor: Power in kW: 2x45
Motor hydraulic unit Power in kW: 15
Range of stage cylinder: Data in mm: 7000
Machine weigh: In kg Approx. 20
Electrical connection data: Markings are attached to the maching
Noise level:
Depends on plant location
and type of grinding
material!
Without noise equipment, in
dB(A):
Approx. 95
With noise equipment in
dB(A):
Depends on type of
soundproof
