“Inventory” page
¾
Clear Inventory
¾ Manual Control
¾ “Next” returns to “Recipe” page
“Manual Control” Page
¾ Reload ON/OFF
¾ Return to the “Inventory” Page
“Setup” Page
¾ Touch the ACS icon and enter in
the “user password”
Hopper Setup
¾ Hopper size
¾ Reload Percentage
Recipe Format (for GH Full
Control Only)
¾ System Rate & Line Speed
¾ Weigh Per Length Mode
¾ Weight Per Area Mode
Extruder Setup
¾ Maximum Extruder RPM
¾ GHF Extruder Max. Throughput
(GH-F Only)
Hauloff Setup (for GH Full
Control Only)
¾ Hauloff enable/disable
¾ Read/ Do Not read speed from
COEX Master
¾ Hauloff Max Speed
¾ Calibrate Encoder
Calibration
¾ Scale Calibration
¾ Direct Scale Readout
¾ Weight/RPM Calibration
“Recipe” Page
(Start)
¾ Extruder RPM is displayed
¾ Extruder throughput is displayed
¾ Line Speed is displayed (GH Full
Control with Line speed option
Only)
¾ Weight Per Length, Weight Per
Area, or simple throughput is
displayed on GH Full Control
versions depending on setup
parameters
¾ GH-F Target throughput and
percent is displayed (GH-F Only)
¾ Access “Inventory” Page
¾ Access “Setup” Page
¾ “Next” to access “Inventory” page.
Panel View Config
¾ Panel view GH version
¾ PLC
GH version
Password
¾ New Password
¾ Verify Password
Alarm Log
¾ View, print, and clear the alarm
log
Alarm Setup
¾ Min System Speed %
¾ Max System Speed %
¾ System Unstable Alarm Time
¾ Maximum allowed reload time
¾ Hopper % for low level alarm
¾ Hopper % for no material alarm
¾ Out of material alarm silence
delay
Network Setup
¾ IP Address
¾ Subnet Mask
¾ Send Config to ENI Module
¾ Enable Ethernet Configurator
¾ Enable or disable coexpert com
Units
¾ Lbs. vs Kgs.
GH Controller Menu Structure
