Process Blower
Note:
The return port is hosed to the process filter inlet.
Regeneration Blower
The air connection
marked “Delivery”
should be blowing air
while the “Return”
connection has suction.
Delivery port
Return port
Regeneration filter
The regeneration filter
inlet shown should be
sucking air in for the
regeneration cycle.
Installation
23
