In addition to the safety devices listed above, these dehumidifying dryers are equipped with a line
cord plug. This allows the operator or maintenance personnel to unplug the system from its
power source and tag it out. The plug can then be tagged with any number of approved electrical
lockout tags available at most electrical supply stores.
Always disconnect and lockout all electrical power and pneumatic (i.e. compressed air)
sources prior to servicing or cleaning the dehumidifying dryer. Failure to do so may result
in serious injury. No one but the person who installed the lockout may remove it.
2-4 Standard Features
Mechanical Features
 Rugged compact frame with sturdy 4” (10cm) casters
 Dual blower dryer with dual desiccant beds and electrically actuated valves
 180ºF – 300ºF (150ºC) standard drying temperature range
 High regeneration temperature control safeties
 13X desiccant (molecular sieve)
 Easy to access process, regeneration, and combustion air filters
 High pressure centrifugal blower
 Dew point +55º F to –90º F (13º C to -68º C)
Electrical Features
 Electrically-actuated air valves
 NFPA79, UL & CUL machinery electrical standards (Electric Dryers) includes:
NEMA 12 controls, components & enclosure
Non-fused electrical disconnect
Solid state relays for process heater control
Branch fusing
Lockable power disconnects
Color touch screen control
Password protection
Temperature display in C or F
Graphical temperature monitor
Data logging option available
Process & Regeneration PID temperature control with auto tune
Dewpoint extend
