3.3 Thermal protection of the motor
To protect the motor from overheating, the motor winding is continuously monitored by a thermostat connected
to the terminals TEMP1 and TEMP2. Whenever an overload or overtemperature condition occurs, the NORDAC
connect will switch off the drive automatically.
If the enable signal [RUN] is not removed, the drive will start up again on its own when the
motor temperature has sufficiently decreased.
To prevent the drive from restarting automatically, evaluation of the readiness-for-operation acknowledgement
[OK] signal can be assigned to a control device (PLC).
3.4 Three-phase brake motors with a NORDAC connect
Whenever a three-phase brake motor is combined with a NORDAC connect motor switch, the wiring needed to
connect the brake is taken care of at the factory.
The brakes used have got a coil voltage of 180 V DC. They are connected to terminals BR1 and BR2 .
4 Technical data
NORDAC connect
Power terminals
Mains voltage 3 AC 380 V ... 440 V ±10%, 47 to 63 Hz
Mains current 0.5...8.0 A
(kW) 0.25...3.0 Motor rating
4-pole three-phase standard
motor
(hp) 1 /
3
...4
Control terminals
Supply voltage
U
24V
I
24V
I
24V
19 V...30 V
< 50 mA + I
OK
< 1A (short-circuit)
Control input (RUN)
U
RUN(AUS)
U
RUN(EIN)
0...5 V, I
RUN
< 2 mA
15..30 V, I
RUN
< 20 mA
Output (OK)
OK
Overtemperature
U
OK
(high)
U
OK
(low)
I
OK
(max)
U
24V
high-impedance
0...0,68A (short-circuit)
Type of enclosure: IP55
Ambient temperature: -10 o C to +50 o C
