Adapter – SK 300E 24 V DC
4 / 4 TI 278910061 - 0814
Assembly
Assembly of the adapter which is used for the migration of the round plug connectors from M8 to M12
should preferably be carried out with commercially available tools.
Information Tightening torque
The stated tightening torques must be used for tightening the hexagonal nut on the M8 plug connector or on the
M12 socket. Please refer to the technical data for the tightening torques.
M8 plug connector SW 9
Spanner sizes
M12 socket SW 13
Pos : 4 /T ec hnis che Inf or mationen/ Zubehör/Adapter 300E 24VDC M 8 St ec ker - M12 Buchse / 278910061/Dr ehmoment- M ont agesc hlüs sel M 8 SW 9 und M 12 SW 13 [ Adapt er SK 300E 24VDC] @ 4\ mod_1383638004298_388. doc x @ 104811 @ @ 1
Information Torque Wrench for Assembly
In order to ensure a secure, sealed and vibration-proof connection, the
round plug connectors, which are equipped with a hexagonal threaded ring
M8 ↔ SW 9, M12 ↔ SW13), should be tightened with a special torque
wrench.
NORD recommends the use of a commercially available assembly tool
with an adjustable, defined tightening torque (e.g. Murrelektronik). Please
refer to the technical data for the tightening torques.
Pos : 5 /T ec hnis che Inf or mationen/ Zubehör/Adapter 300E 24VDC M 8 St ec ker - M12 Buchse / 278910061/ Weiter führende D okument ati onen [ Adapt er SK 300E 24VDC] @ 4\ mod_1383573355276_388. doc x @ 104751 @ 5 @ 1
Further documentation ( www.nord.com )
Document Name Document Name
BU 0020 PROFIBUS DP Manual BU 0220 PROFIBUS DP for SK 0200E
BU 0180 SK 180E…SK 190E frequency inverter manual BU 0300 SK 300E frequency inverter manual
BU 0200 SK 2xxE frequency inverter manual TI 275274507 Connection extension SK TIE4-M12-POW
